Quick Details

  • Material: PTFE
  • Use: Masking
  • Adhesive Side: Single Sided
  • Adhesive: Silicone
  • Adhesive Type: Hot Melt, Pressure Sensitive, Water Activated
  • Feature: Heat-Resistant
  • Design Printing: No Printing
  • Place of Origin: Jiangsu, China (Mainland)
  • Brand Name: Youngsun
  • Model Number: YS7013AJ
  • nonstick: high temperature resistant

Packaging & Delivery

Packaging Details One roll in a carton with inner packing with air bubble film inner.
Delivery Time within 15days after receiving payment
Product Description

PTFE Adhesive Tapes -PTFE coated adhesive backed tapes are high performance products that offer excellent release characteristics whilst being able to cope with extreme tempretures. They are manufactured with a high temperature resistant surface with pressure sensitive silicone adhesive.



Features & Benefits

Non stick PTFE materials prevent the build up of molten film and plastic on its surface.

The temperature resistant PTFE coating allows high and low operating temperatures.

A yellow corrugated release liner is used on our PTFE tapes providing fast and easy removal.

Manufactured in varying thicknesses to cover a wide range of applications our PTFE tapes are of the highest quality available in today’s market.

Material Properties

·Temperature resistance: -70 degrees~260 degrees

·Non-Stick optimal release

·Pressure sensitive silicone adhesive

·Thermostatic cycles of 4 hours at 200oc

·Low friction

· Exceptional wear life



Applications

PTFE adhesive tapes are often used as a release tape for the protection of sealing jaws and heat-sealing wires on equipment such as bag and L- sealing machines. They can also be found in vacuum and blister packing operations too.



Additional Information:

Available in widths from 5mm up to 1000mm wide and are slit from stock.

Rolls lengths of 30/50 metres as standard.

Please contact our sales team to make your enquiry, details are available upon request.

Main Specification:



      Model
  Fabrics
Thickness
  Total Thickness
  Standard Width
           (mm)
     Length
       (m)
   Adhesion to Steel
          (N/50mm)
   Tensile Strength
        (N/50mm)
   YS7008AJ
   0.08mm
    0.13mm
          1000
    10~50
              22
           1600
   YS7013AJ
   0.13mm
    0.18mm
          1000
    10~50
              20
           1100
   YS7018AJ
   0.18mm
    0.23mm
          1000
    10~50
              18
           1850
   YS7025AJ
   0.25mm
    0.30mm
          1000
    10~50
              16
           2250



Packing-Adhesive
